- Minimum space of 20 Mtrs diameter required for this system
- The highest level can be 12 Levels
- Each level can park 8 to 12 cars
Features
- Fully Automated Parking System
- Fast and safe
- Modular Steel Structure can be used
- Multiple Entrances / Exits possible to increase efficiency
Technical Parameters
Lifting Motor | 11.0 / 30.0 KW |
Lifting speed | 50-80 m/minute |
Carrier Speed | 30-50 m/minute |
Lifting Method | Steel Rope/Chain |
Operation | Touch Screen + RFID card |
Power Supply | AC 400 V / 50 Hz, Three Phase, 5 Wire |
Entry / Exit | Auto Doors |
Car Dimensions
Length (mm) | 5200 |
Width (mm) | 2200 |
Height (mm) | 2000 |
Weight (kg) | 2300 |
Note: Customized design according to car sizes available
