Long Way Garage Parking

Lootah Long Way Garage Parking - LPS 700 A

  • This system can be used in long narrow spaces
  • The minimum distance can be 6.0 Mtrs
  • More car in less space

Features

  • Fully Automated Parking System
  • Fast and safe
  • Modular Steel Structure can be used

Technical Parameters

Lifting Motor11.0 / 30.0 KW
Lifting speed50-80 m/minute
Carrier Speed30-50 m/minute
Lifting MethodSteel Rope/Chain
OperationTouch Screen + RFID card
Power SupplyAC 400 V / 50 Hz, Three Phase, 5 Wire

Car Dimensions

Length (mm)5200
Width (mm)2200
Height (mm)2000
Weight (kg)2300

Note: Customized design according to car sizes available
